125Ah 24v Marine Lithium Battery For Trolling Motor, Electric Outboard Motor

125Ah 24v Marine Lithium Battery For Trolling Motor, Electric Outboard Motor

125ah 24v marine lithium battery

125ah lithium battery for trolling motor

yacht 24v marine lithium battery

Place of Origin:

China

Brand Name:

Bonnen Battery

Certification:

Compliance with MSDS, UN38.3, CE, CB, IEC 62619, UL

Model Number:

EM-LFP24-125A

Contact Us
Request A Quote
Product Details
Voltage:
24V
Capacity:
125Ah
Total Energy:
3.2KWH
Battery Chemistry:
LIFEPO4 Battery
Application:
Trolling Motor, Electric Yacht, Electric Outboard Motor
BMS:
Smart BMS+relay
Material Of Battery Case:
AL
Warranty:
3 Years
Customization Options:
Yes
Payment & Shipping Terms
Minimum Order Quantity
2 units
Price
Special Offers Available
Packaging Details
wooden case
Delivery Time
30 days
Payment Terms
T/T, L/C, ACH, Fedwire Payment, SEPA Credit Transfer, Electronic Fund Transfer
Supply Ability
5000 units /month
Product Description

24V 125Ah Lithium Battery For Trolling Motor, Electric Yacht, Electric Outboard Motor



Product Introduction



Bonnen Battery offers the longest-lasting and most powerful 24V trolling motor batteries available. Our deep cycle, 24V lithium trolling motor batteries are engineered with proprietary software and design construction, enabling higher amp hours in a smaller battery size. The result is the marine industry's highest energy density battery, with up to 10 times the lifespan of conventional marine batteries. Our 24V marine batteries ensure extended time on the water, whether you're trolling in calm conditions or battling strong winds. Bonnen batteries are perfect for deep cycle applications in various marine environments, seasons, and temperatures.



Product Features



1. Longer Lifecycle: Bonnen Lithium batteries offer a longer lifecycle, requiring no maintenance and lasting up to 5 times longer than lead-acid batteries. They can retain up to 80% of their capacity after 4,000 cycles.


2. Lightweight: Lithium batteries are approximately half the weight of lead-acid batteries while providing more power.


3. Quick Charge: Lithium batteries feature significantly faster charge times, enabling a full charge in as little as 1 hour. A recommended range of 2-5 hours is advised.


4. Higher Capacity: Lithium batteries offer 25%-50% more capacity than lead-acid batteries and maintain full power throughout their discharge.


5. Partial State of Charge (PSOC): These batteries are not adversely affected when maintained in a partial state of charge.


6. Temperature Tolerant: These batteries can operate effectively in both high and low temperatures and do not emit heat, allowing for flexible storage options.


7. LiFePO4: Lithium iron phosphate chemistry is considered the safest battery technology available on the market.



125Ah 24v Marine Lithium Battery For Trolling Motor, Electric Outboard Motor 0



Product Specification



No. Item Name Basic Parameter
1 Nominal capacity 125Ah
2 Minimum capacity ≥125Ah
3 Watt hour 3200Wh
4 Nominal voltage 25.6V
5 Operating voltage range 20V~29.2V
6 Standard charging current 60A
7 Maximum continuous charge current 125A
8 Standard discharging current 125A
9 Maximum continuous discharge current 125A
10 Cycle life ≥4000 cycles (80% DOD)
11 Operating temperature -20~55℃
12 Storage temperature -20~55℃
13 Charging heating Yes
14 Shipment voltage ≥25.6V
15 Communication mode CAN/RS485
16 Size L588*W210*H263(mm)
17 Weight 31kgs



Product Benefits



1. Custom Battery Packs: Personalize your electric boat projects with our adaptable lithium battery packs. Whether you need a compact design for small vessels or a high-capacity system for larger applications, our battery packs are tailored to meet the unique requirements of your project.



2. Unparalleled power and efficiency: Experience with our lithium battery boasting a 24V output and 125Ah capacity. Keep your electric marine operations running smoothly with a consistent power supply and extended runtimes, ensuring confident cruising every time.



3. Significantly lighter and more compact: Compared to lead-acid batteries, This compactness allows for easy integration into smaller marine vessels, saving valuable onboard space. Additionally, they offer prolonged power delivery, making them ideal for high-speed cruising or powering multiple electronic devices simultaneously.



4. Extended usage without frequent replacements: Our lithium batteries last five times longer than lead-acid batteries, providing extended usage without frequent replacements. This brings reduced maintenance costs, enhanced reliability, and performance, ensuring uninterrupted enjoyment on your boating adventures.



Product Applications



Marine and Boating Applications: It can power electric boats, sailboats, yachts, or other marine vessels. It provides a quiet and clean energy source for propulsion, onboard electronics, and auxiliary systems.



Emergency Backup Power: Be prepared for power outages or emergencies by utilizing the battery as a backup power source. It can keep essential devices running, such as communication equipment, medical devices, emergency lighting, and security systems, ensuring safety and convenience during critical times.



Camping and Outdoor Adventures: Take the battery on camping trips or outdoor adventures to power camping lights, portable refrigerators, fans, charging stations, and other equipment.



Industrial Equipment and Machinery: This battery can power various industrial equipment and machinery, such as forklifts, automated guided vehicles (AGVs), warehouse equipment, or material handling systems. It offers a clean and efficient alternative to traditional fuel-powered machinery.



125Ah 24v Marine Lithium Battery For Trolling Motor, Electric Outboard Motor 1



​The Process Flow & Duration Estimation



Step 1: Battery Specification Discussion (1-3 days)

We initiate discussions to gather all necessary details such as application, voltage, discharging current, charging current, IP grade, maximum case dimensions, etc. Once all requirements are clarified, we finalize the battery specification.

125Ah 24v Marine Lithium Battery For Trolling Motor, Electric Outboard Motor 2

Step 2: Solution Drawing Design And Confirmation (3 days for initial drawing)

Bonnen Battery experienced engineering team will create a design drawing based on the discussed specifications. We provide this drawing for your review and confirmation. If needed, we'll make adjustments based on your feedback. You'll receive three design options at no additional cost.

125Ah 24v Marine Lithium Battery For Trolling Motor, Electric Outboard Motor 3

Step 3: Prototype/ Bulk Production (30 days)

Upon confirmation of the final design drawing, Bonnen Battery commence manufacturing either for prototyping or bulk production. This process typically takes around 30 days to complete.

125Ah 24v Marine Lithium Battery For Trolling Motor, Electric Outboard Motor 4

Step 4: Shipping (Dependent on distance)

Bonnen Battery offers various shipping options tailored to your needs. Air shipping is the quickest but more costly, ideal for urgent orders. Alternatively, sea shipping is the most economical option, though it requires a longer transit time compared to air freight.

125Ah 24v Marine Lithium Battery For Trolling Motor, Electric Outboard Motor 5



FAQ

Q: What sets Bonnen apart in the lithium battery industry?
A: Bonnen is a distinguished lithium battery manufacturer with over a decade of expertise. We have successfully delivered comprehensive lithium battery solutions globally, showcasing our commitment to quality and innovation.

Q: Is there a possibility of receiving a discount for large quantity orders?
A: Certainly! We offer competitive pricing, and larger quantity orders will benefit from reduced prices. Feel free to contact our sales team to discuss specific pricing details for your bulk order.



Q: How can I place an order for this Lithium Ion Marine Battery?
A: Placing an order is simple. Visit our website, explore the product details, and use the provided contact options to reach our sales team. They will guide you through the ordering process and answer any additional questions you may have.



Q: Can I receive technical support for integrating the battery into my electric boat project?
A: Absolutely! We provide comprehensive technical support to assist you in seamlessly integrating our lithium-ion battery into your electric boat projects. Our team is dedicated to ensuring your project's success.



Q: Can I visit Bonnen's manufacturing facilities to witness the production process?
A: Certainly! We welcome our clients to visit our state-of-the-art manufacturing facilities. Contact our team to schedule a visit, and we'll provide you with insights into our advanced production processes and quality control measures.



Q: How does Bonnen ensure the safety of its lithium-ion batteries during transportation?
A: Safety is our priority. Bonnen follows strict packaging and transportation guidelines compliant with international regulations, ensuring the secure and safe delivery of our lithium-ion batteries to your location.



Q: Can Bonnen Battery assist with battery management systems (BMS) integration?
A: Absolutely! We offer expertise in battery management systems (BMS) integration. Our team can provide guidance and support to ensure the seamless incorporation of our lithium-ion battery with the BMS in your electric boat projects.



Q: What is the warranty coverage for Bonnen's lithium-ion marine batteries?
A: Our lithium-ion marine batteries come with a 3 years warranty, providing you with confidence and assurance in the durability and performance of our products. Please refer to our warranty policy for detailed terms and conditions.



Q: What is the expected lifespan of the lithium-ion battery?
A: The battery is designed for longevity, with an expected lifespan of over 10 years under normal usage conditions.



Q: Can this battery be customized for specific electric boat models?
A: Yes, our lithium-ion battery solutions are highly customizable to meet the unique specifications of various electric boat models.



Q: How does the rapid charging capability benefit my electric boat project?
A: Rapid charging minimizes downtime, ensuring your electric boats spend more time on the water and less time waiting for a charge.



Q: Can the battery be used in different marine environments, including saltwater conditions?
A: Yes, the battery is designed to withstand marine environments, including saltwater conditions, ensuring reliable performance.



Q: How does the compact design of the battery optimize space on electric boats?
A: The compact and lightweight design allows for efficient space utilization, providing electric boat manufacturers with more design flexibility.



Q: How can I get a customized quote for my electric boat project?
A: To receive a customized quote, simply visit our website and fill out the quote request form. Our team will promptly assess your project needs and provide a tailored solution.
