Place of Origin:
China
Brand Name:
Bonnen Battery
Certification:
Compliance with MSDS, UN38.3, CE, CB, IEC 62619
Model Number:
EV-LFP12-100
Are you tired of traditional lead-acid batteries weighing down your golf cart? Experience the power of Bonnen's lithium batteries, offering lightweight and long-lasting performance on the green.
Product Features
1. High Capacity: With its generous 100AH capacity, this lithium battery ensures ample power supply for prolonged usage during your golfing sessions, offering extended playtime without interruptions.
2. Lightweight Design: Despite its impressive capacity, the 12V100AH battery remains remarkably lightweight, effectively reducing the overall weight burden on your golf cart, enhancing maneuverability and efficiency on the course.
3. Maintenance-Free: Bid farewell to frequent maintenance tasks as the stable chemistry of lithium batteries eliminates the need for regular upkeep, allowing you to focus more on your game and less on battery care.
4. Easy Expansion: The Bonnen 12V100Ah batteries seamlessly support the addition of four battery packs either in series or parallel configuration, offering flexibility and scalability to meet your evolving power needs with ease.
5. Direct Drop Placement: The Bonnen 12V100Ah battery features a standard SLA battery case design, enabling effortless replacement of lead-acid batteries without concerns about dimension constraints, ensuring a hassle-free transition to lithium power.
6. IP67 Protection: Encased in a robust plastic housing, this battery boasts IP67-rated protection, effectively shielding it from dust and water ingress, ensuring reliable performance even in challenging environmental conditions.
Product Specification
| No. | Item Name | Basic Parameter |
| 1 | Voltage | 12V |
| 2 | Battery system whole energy(KWh) | Rated:1.28kWh |
| 3 | Battery system whole capacity(Ah) | Rated:100Ah |
| 4 | Battery system working temperature | Discharge -20~45℃,charge 0~45℃ |
| 5 | Battery surrounding environment relative humidity | 10%~85% |
| 6 | Battery storage temperature | -20～45℃ |
| 7 | Battery standard charging current(23±2℃) | 75A |
| 8 | Battery Max charging current(23±2℃) | 150A |
| 9 | Battery standard discharging current(23±2℃) | 100A |
| 10 | Battery continuous discharging current(23±2℃) | 150A |
| 11 | Battery discharge peak current(5s)(23±2℃) | 300A |
| 12 | Battery system insulation resistance testing value | ≥20mΩ |
| 13 | Insulation Resistance Testing | ≥20MΩ |
| 14 | Battery Dimension | L(330.0mm)*W(173.2mm)*H(214.8mm) |
| 15 | Battery system waterproof grade | IP67 |
| 16 | Battery Weight | 12.08KGS |
Product Benefits
Long-lasting performance: Enjoy extended golfing sessions without worrying about battery life.
Lightweight design: Easily maneuver your golf cart without added bulk.
Series and parallel connection: Easy to configure the wanted voltage and capacity by series or parallel wiring.
Eco-friendly: Reduce your carbon footprint with a lithium battery that's better for the environment.
Reliable power: Count on consistent performance round after round.
Product Applications
The 12V100AH lithium battery from Bonnen Company is ideal for various applications, including electric utility golf carts, electric trolley carts, and recreational vehicles. Its compact size and high energy density make it perfect for powering EZ Go, Club Car, and Yamaha golf carts with long-lasting performance and reliability.
The Process Flow & Duration Estimation
Step 1: Battery Specification Discussion (1-3 days)
We initiate discussions to gather essential details, including application, voltage, discharging and charging currents, IP grade, maximum case dimensions, etc. Once all requirements are clarified, we finalize the battery specifications to ensure alignment with your needs.
Step 2: Solution Drawing Design And Confirmation (3 days for initial drawing)
Bonnen Battery's experienced engineering team will craft a design drawing according to the specifications we've discussed. We'll present this drawing to you for review and confirmation. If any adjustments are required, we'll gladly accommodate your feedback. You'll receive three design options at no extra charge.
Step 3: Prototype/ Bulk Production (30 days)
Once the final design drawing is confirmed, Bonnen Battery will initiate manufacturing, whether for prototyping or bulk production. This process generally takes approximately 30 days to fulfill.
Step 4: Shipping (Dependent on distance)
Bonnen Battery provides a range of shipping options customized to suit your requirements. Air shipping, while more expensive, is the fastest and perfect for urgent orders. On the other hand, sea shipping is the most cost-effective option, albeit with a longer transit time compared to air freight.
FAQ
Q: What makes Bonnen's lithium battery stand out from traditional lead-acid batteries?
A: Bonnen's lithium battery offers lightweight and long-lasting performance compared to traditional lead-acid batteries, providing a superior experience on the golf course.
Q: How does the lightweight design benefit golf cart users?
A: Despite its impressive capacity, the 12V100Ah lithium battery remains remarkably lightweight, enhancing maneuverability and efficiency on the course without adding bulk to the cart.
Q: Is regular maintenance required for Bonnen's lithium battery?
A: No, the stable chemistry of lithium batteries eliminates the need for frequent maintenance tasks, allowing users to focus more on their game and less on battery care.
Q: Can Bonnen's lithium battery support additional battery packs?
A: Yes, the 12V100Ah lithium batteries seamlessly support the addition of four battery packs either in series or parallel configuration, offering flexibility and scalability to meet evolving power needs.
Q: How easy is it to replace lead-acid batteries with Bonnen's lithium battery?
A: Bonnen's lithium battery features a standard SLA battery case design, enabling effortless replacement of lead-acid batteries without concerns about dimension constraints, ensuring a hassle-free transition to lithium power.
Q: What level of protection does Bonnen's lithium battery offer?
A: Encased in a robust plastic housing with IP67-rated protection, this battery shields against dust and water ingress, ensuring reliable performance even in challenging environmental conditions.
Q: What are the main benefits of using Bonnen's lithium battery for golf carts?
A: Users can enjoy long-lasting performance, lightweight design for easy maneuverability, series and parallel connection options, eco-friendliness, and reliable power round after round.
Q: What applications is Bonnen's lithium battery suitable for?
A: Bonnen's 12V100Ah lithium battery is ideal for electric utility golf carts, electric trolley carts, and recreational vehicles, powering popular brands like EZ-GO, Club Car, and Yamaha with reliability and performance.
Q: How many cycles can Bonnen's lithium battery endure?
A: Bonnen's lithium battery offers an impressive 6000 cycles, providing long-lasting performance and reliability for extended use on the golf course.
Q: Can Bonnen's lithium battery withstand challenging environmental conditions?
A: Yes, with its IP67-rated protection, Bonnen's lithium battery is designed to withstand dust and water ingress, ensuring reliable performance even in harsh outdoor environments.
Q: Is Bonnen's lithium battery environmentally friendly?
A: Yes, Bonnen's lithium battery helps reduce carbon footprint as it is eco-friendly compared to traditional lead-acid batteries, offering a more sustainable power solution for golf carts.
Q: What is the warranty period for Bonnen's lithium battery?
A: Bonnen offers a standard warranty period for their lithium battery, ensuring peace of mind for customers regarding product quality and performance.
Q: What safety features does Bonnen's lithium battery offer?
A: Bonnen's lithium battery is equipped with a built-in 150A BMS (Battery Management System) to ensure safe and reliable operation, protecting against overcharging, over-discharging, and short circuits.
