Place of Origin:
China
Brand Name:
Bonnen Battery
Certification:
Compliance with MSDS, UN38.3, CE, CB, IEC 62619, ECE-R100
Model Number:
EV-LFP72-400
Drive into the future with Bonnen's cutting-edge EV lithium batteries. Powering your electric vehicle with efficiency and reliability, our lithium batteries redefine sustainability on the road. Experience super performance and extended range, all while reducing your carbon footprint. With options like our 72V 400AH model, you can enjoy even greater power and endurance for your electric vehicle journey. Choose Bonnen for a greener tomorrow.
Product Features
1. High Energy Density: Bonnen's 72V 400AH lithium iron phosphate battery boasts an impressive energy density, providing extended usage time for various applications.
2. Long Cycle Life: With advanced technology, Bonnen ensures a long cycle life for its batteries, offering reliability and durability for prolonged use.
3. Stable Performance: Experience consistent and stable performance with Bonnen's lithium iron phosphate battery, even under demanding conditions, ensuring reliable power output.
4. Enhanced Safety Features: Bonnen prioritizes safety with built-in protection mechanisms, safeguarding against overcharging, over-discharging, and short circuits for peace of mind.
5. Environmentally Friendly: Choose Bonnen's lithium iron phosphate battery for an eco-conscious power solution, free from harmful heavy metals and with minimal environmental impact throughout its lifecycle.
6. Versatile Applications: From electric vehicles to renewable energy storage systems, Bonnen's 72V 400AH battery caters to a wide range of applications, offering flexibility and adaptability to various industries and projects.
Product Specification
| No. | Item Name | Basic Parameter |
| 1 | Voltage | 73.6V |
| 2 | Battery system whole energy(KWh) | Rated:29.44kWh |
| 3 | Battery system whole capacity(Ah) | Rated:400Ah |
| 4 | Battery system working temperature | Discharge -20~45℃,charge 0~45℃ |
| 5 | Battery surrounding environment relative humidity | 10%~85% |
| 6 | Battery storage temperature | -20～45℃ |
| 7 | Battery standard charging current(23±2℃) | 100A |
| 8 | Battery Max charging current(23±2℃) | 200A |
| 9 | Battery standard discharging current(23±2℃) | 400A |
| 10 | Battery continuous discharging current(23±2℃) | 400A |
| 11 | Battery discharge peak current(5s)(23±2℃) | 600A |
| 12 | Battery system insulation resistance testing value | ≥20mΩ |
| 13 | Insulation Resistance Testing | ≥20MΩ |
| 14 | Waterproof grade of battery case | IP67 |
| 15 | Battery system waterproof grade | IP67 |
| 16 | Cooling system | Air cool |
Enhanced Performance: Experience heightened performance levels with Bonnen's 72V 400AH lithium iron phosphate battery, delivering consistent power output for extended durations. Say goodbye to sluggish starts and enjoy seamless acceleration on your electric vehicle or machinery.
Extended Range: Extend your adventure or workday with confidence, thanks to the impressive energy density of Bonnen's battery. With longer intervals between charges, you can cover more ground or complete more tasks without interruptions, enhancing productivity and convenience.
Fast Charging Capability: Maximize your uptime with rapid charging capabilities. Bonnen's lithium iron phosphate battery boasts fast charging technology, reducing downtime and ensuring you spend more time on the move and less time waiting for your battery to recharge.
Eco-Friendly Solution: Embrace sustainability with Bonnen's environmentally friendly lithium iron phosphate battery. By choosing this clean energy solution, you're reducing your carbon footprint and contributing to a greener future without compromising on performance or reliability.
Enhanced Safety Features: Prioritize safety without sacrificing performance. Bonnen's battery is equipped with advanced safety features, including thermal stability and overcharge protection, ensuring peace of mind during operation. Safeguard yourself and your equipment against potential hazards with Bonnen's reliable power solution.
Product Applications
Explore the versatile applications of Bonnen's 72V 400AH lithium iron phosphate battery, ideal for AGVs, golf carts, forklifts, UTVs, and more. Experience reliable power solutions designed to optimize performance and efficiency across various industries. Unlock the potential of clean energy with Bonnen's cutting-edge battery technology.
The Process Flow & Duration Estimation
Step 1: Battery Specification Discussion (1-3 days)
We initiate discussions to gather essential details, including application, voltage, discharging and charging currents, IP grade, maximum case dimensions, etc. Once all requirements are clarified, we finalize the battery specifications to ensure alignment with your needs.
Step 2: Solution Drawing Design And Confirmation (3 days for initial drawing)
Bonnen Battery's experienced engineering team will craft a design drawing according to the specifications we've discussed. We'll present this drawing to you for review and confirmation. If any adjustments are required, we'll gladly accommodate your feedback. You'll receive three design options at no extra charge.
Step 3: Prototype/ Bulk Production (30 days)
Once the final design drawing is confirmed, Bonnen Battery will initiate manufacturing, whether for prototyping or bulk production. This process generally takes approximately 30 days to fulfill.
Step 4: Shipping (Dependent on distance)
Bonnen Battery provides a range of shipping options customized to suit your requirements. Air shipping, while more expensive, is the fastest and perfect for urgent orders. On the other hand, sea shipping is the most cost-effective option, albeit with a longer transit time compared to air freight.
FAQ
Q. What type of electric vehicles is the 72V 400Ah LiFePo4 Lithium Battery suitable for?
A: The 72V 400Ah LiFePo4 Lithium Battery is designed to cater to various electric vehicles, including electric cars, utility vehicles, and retrofit conversion electric vehicles. Its versatile design and robust performance make it an ideal choice for a wide range of EV projects.
Q. What is the expected lifespan of the battery?
A: The battery offers exceptional longevity, with a cycle life exceeding 6000 cycles. This means it can sustain reliable performance over an extended period, making it a cost-effective choice for drivers seeking durability and longevity.
Q. Is the battery suitable for harsh driving conditions?
A: Absolutely. Our battery is built to withstand shocks and vibrations with excellent seismic resistance, meeting rigorous automotive standards for durability. Drive with confidence knowing that our battery can handle the demands of the road, providing stability and reliability in any conditions.
Q. Can the battery be used for fleet operations or battery swapping projects?
A: Yes, our battery offers versatile performance suitable for fleet operations and battery swapping projects. Whether for commercial fleets or shared mobility services, its superior charge and discharge capabilities ensure seamless operation and efficiency, optimizing performance and reducing downtime.
Q. Does the battery feature real-time monitoring capabilities?
A: Yes, our battery comes equipped with real-time monitoring capabilities, allowing drivers to track various battery parameters and performance metrics. From state of charge to temperature monitoring, our system provides comprehensive insights, enabling proactive maintenance and maximizing battery lifespan.
Q. Can the 72V 400Ah LiFePo4 Lithium Battery be customized for specific electric vehicle models?
A: Yes, Bonnen Battery specializes in customized solutions for electric vehicle manufacturers and project managers. We can tailor the battery to fit specific vehicle requirements, ensuring optimal performance and compatibility.
Q. Can the battery be safely transported and installed in electric vehicles?
A: Yes, our battery is designed with safety in mind and complies with all relevant transportation and installation regulations. Our team ensures proper packaging and handling procedures to guarantee the safe transportation and installation of the battery in electric vehicles.
Q. Does the battery come with a warranty or guarantee?
A: Yes, we offer a warranty or guarantee on our batteries to provide peace of mind to our customers. We can send the details regarding warranty coverage and terms to you by email.
Q: How does Bonnen Battery ensure product quality and reliability?
A: We maintain stringent quality control measures throughout the manufacturing process to ensure that each battery meets our high standards for performance, reliability, and safety. Additionally, our batteries undergo rigorous testing and certification procedures to guarantee compliance with industry regulations and standards.
